New pelvic profile; for a longer life and a better cutting result.
Precise cutting edges, whatever the type of wire: soft wire, modern materials and piano wires, according to the following dimensions:- 192A.16CPE: 2.0mm 210 kg/mm²- 192A.18CPE: 2.2mm 205 kg/mm²- 192A.20CPE: 2.5 mm 200kg/mm²
Geometry that significantly reduces effort during cutting, thanks to a displaced axis and a specific cutting profile.
High strength carbon steel alloy, induction hardened cutting edges.
Ergonomic bi-material handles, resistant to chemical agents, with:- Return spring- Suspension eye (the suspension eye increases the nominal length by 10 mm)
Version: Chrome plated, corrosion resistant
Technical data
Diameter D max. (mm): 2
Length (mm): 160
Thickness (mm): 10
Head Height C (mm): 180
Head Width B (mm): 24
Head Width B1 (mm): 15
Weight (kg): 0.2
Standards:: NF ISO 5749, ISO 5749, DIN ISO 5749, ASME B107.500
