DCN692P2K Battery Construction Tacker 18V 5.0Ah XR Li-ion in Toughsystem Box

Scope of supply

• 1 piece DeWALT DCN692 Battery Construction Tacker 18V
• 1 piece XR Multicharger DCB115
• 2 pieces Battery 18V 5.0Ah Li-Ion DCB184
• 1 pcs Adjustable Belt Hook
• 1 pcs Nose tip
• 1 pcs DS400 Sturdy Carrying Case

Special characteristics

• 18V XR Battery Construction tacker with 5.0 Ah XR batteries and with Brushless motor technology
• The Brushless motor technology provides enough power to drive a 90mm ring nail in soft wood and a 63mm ring nail in hard wood
• Manual nail-by-nail application for precision finishing or "rapid fire" application for production work
• The 5.0 Ah XR batteries deliver extreme runtime and offer the option to be interchanged with other 18V XR tools
• The machine provides consistent performance in a temperature range of -15 °C to 50 °C and requires minimal maintenance
• The best vibration values ​​in its class and a minimum of noise pollution ensure optimum operation
• The magazine with a 30-34° angle, will accept most D head or off center round head nails
• Rotatable belt hook increases ease of use
• The impact depth can be easily adjusted thanks to the very easy to operate depth adjustment
• Increased visibility and durability and protection of the workpiece thanks to the non mar nose tip
• Thanks to the ergonomic design, it is even possible to work between rafters with only 400mm spacing
• Because of the gas-free working, you will be able to save considerably on your work costs
• Thanks to the keyless release of the firing pin, the user loses a minimum of time
• The battery technology allows you to work "cordless", which increases ease of use and work safety
• The contact mechanism can be locked to prevent accidental firing of nails
• The "dry fire" block prevents firing without nails in the magazine

Technical data

• width: 125 millimeters
• length: 345 millimeters
• battery capacity: 5.0 amp hours
• height: 338 millimeters
• weight: 4.1 kilograms
• temperature range: -15 to 50 °C
• voltage: 18 volts
• controls: rapid fire or nail by nail
• unblocking system: yes
• nail diameter: 2.8 - 3.3 millimeters
• loader angle: 30 - 34 degrees angle
• loader capacity: up to 55 nails
• integrated belt hook: Yes
• nail length: 50 - 90 millimeters
• mode of use: optional
• loading: double loading system from behind
• battery type: XR Li-Ion
• max. impact energy (EPTA 05/2009): 105 joules
• error indicator: LED error indicator
