Makita AN613 Construction Tacker 8 Bar

Makita AN613 Construction Tacker

Scope of supply

• 1 piece Makita AN613 Construction Tacker 8 bar
• 18ml tacker oil 181434-7
• 1 pcs Allen key 5mm HY00000953
• 1 piece Nose adapter AN613 HY00001072
• 1 pcs Allen key 3.0mm HY00001104
• 1 pcs Allen key 4.0mm HY00001105

Features and strengths

• Suitable for (2.3 - 2.5 mm) nails on a roll with a length of 38 to 65 mm.
• Suitable for wood construction work: timber frame construction, floors, facade cladding, roof boarding.
• Easy depth adjustment with rotary wheel, adjustable without tools.
• Equipped with a choice system for single or continuous firing.
• Equipped with fixed carrying hook.
• Magazine for 200 - 300 nails.
• With built-in air blower, operated with a button on the back of the handle.

Technical data

• Soft grip: yes
• Working pressure: 4.9 - 8.3 bar
• Dim. LxWxH: 275x127x319 mm
• Weight (EPTA): 2.2 kg
• Vibration ah no load: 3.06 m/s²
• Vibration (K) no load: 1.5 m/s²
• Nail diameter: 2.3 - 2.5mm
• Nail length: 38 - 65 mm
• Magazine: 200 - 300 pcs.
• Magazine angle: 15 °
• Shape: Roll
• Wood on wood: yes
• Controls: Single and continuous shot
• Depth adjustment: yes
• Sound pressure level (LpA): 116.3 dB(A)
• Uncertainty (K) (LpA): 1.5 dB(A)
